Product Details:
Payment & Shipping Terms:
|
| Product Name: | Customized Electric Material Handling Flat Car In Industrial | Table Size: | Customized |
|---|---|---|---|
| Color: | Customized | Running Speed: | 0-20m/min |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | ||
| Highlight: | industrial transfer car,industrial motorized carts |
||
Customized Material Transfer Cart , Electric Material Handling Trolley Transfer Flatbed Cart
Product Description
Henan Perfect Handling Equipment Co., Ltd is a collection of research and development, design, manufacturing as one of professional international manufacturing company of Material Transfer Truck . Our company has been founded for 13 years and has become enterprise in the motorized Material Transfer Truck business.
Our products have gotten 8 patents and exported to more than 50 countries and regions. Our main products include battery operated transfer trolley, hydraulic motor driven mobile trolley, cable operated transfer trolley, industrial trailers, non-powered transfer cart, electric rail car, motorized transporter, coils transport trolley, ladle transfer trolley and so on.
Site map for customer use
Details of Motorized trackless cart
Technical Parameter of Motorized trackless cart
| Model | BWP-5t | BWP-20t | BWP-30t | BWP-40t | BWP-50t |
| Rated Load(t) | 5 | 20 | 30 | 40 | 50 |
| Max. Wheel Load (t) | 2.8 | 5.6 | 7.7 | 10 | 12 |
| Ground Requirement | Cement floor or Steel plate ground | ||||
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 |
| Table Size (mm) | 3000 X 2000 | 4500 X 2200 | 5000 X 2200 | 5500 X 2300 | 6000 X 2300 |
| Height (mm) | 450 | 600 | 650 | 700 | 700 |
| Wheel Base (mm) | 1500 | 1700 | 1700 | 1800 | 1800 |
| Axles Distance (mm) | 2500 | 3900 | 4300 | 4800 | 5200 |
| Turning Radius (mm) | 2501 | 3901 | 4301 | 4801 | 5201 |
| Turning Structure | Mechanical | ||||
| Motor Power (KW) | 3.5 | 7 | 10 | 12 | 15 |
| Wheel Diameter (mm) | 300 (4) | 400 (4) | 400 (6) | 500 (6) | 500 (6) |
| Wheel Material | ZG55+hydropurture | ||||
| Running Speed (m/min) | 0-15 | 0-12 | |||
| Brake Principle | Electric magnetic brake | ||||
| Operation Method | Raido Remote Control | ||||
| Battery Maintainance | Free of maintainance | ||||
| Charger's Installation | Installed on cart | Split-type | |||
| Cart Color | Customized | ||||
| Charger's Function | Automatically cut off the power when the battery is fully charged | ||||
| Radar Control | 3-0.3 m, Automatic stop for obstacles | ||||
| Warning Equipment | Horn and Flash Light | ||||
| Other Functions | Turning light, night light and power display | ||||
Certificates
1. Q: What is the size and load of this 20 ton transfer cart ?
A:The size and load of our this 20 ton transfer cart is customized design according to your requirement.
2. Q: How should I operate this 20 ton transfer cart ?
A: The 20 ton transfer cart is controlled by pendant & remote radio control. The controller could be push button or joy-sticker.
3. Q: Is there any braking system on this 20 ton transfer cart ?
A: Yes, there are electromagnetic brakes on the 20 ton transfer cart. When the 20 ton transfer cart is power off, the brake will work automatically. And there are emergency stop buttons on the remoter and the 20 ton transfer cart, you can push it for emergency stop.
4. Q:What is the warranty period? What kind of service do you offer in the warranty period?
A: The warranty period for our product is 12 months from the time we delivery, during the warranty period, we will send spare parts to you on our own cost if damaged because of bad quality, and we will guide you how to replace it. If necessary, our engineer is available to your factory for maintenance.
5. Q: How do you transport the 20 ton transfer cart and what is the package ?
A: For the big part, we will pack it with tarpaulin and wood pallet on the bottom of the 20 ton transfer cart to prevent it from moving. For the small part, we will pack it in wood case.
6. Q: What is the leading time, delivery term, and payment term ?
A: Usually our leading time is 45 days, for some special 20 ton transfer cart, such as hydraulic lifting 20 ton transfer cart, it maybe longer to 60 days. About the delivery term, we accept EXW, FOB, CIF, DDU. About the payment, we accept T/T or L/C.
