Product Details:
Payment & Shipping Terms:
|
| Product Name: | Steel Coil Transporter Cart | Power Supply: | Battery Powered |
|---|---|---|---|
| Operation Mode: | Pandent And Remote Controller | Running Distance: | Unlimited |
| Capacity: | 20T Customized | Application: | Steel Factory |
| Warranty: | 1 Year | Color: | YELLOW Customized |
| Wheel Type: | Cast Steel Wheel | Usage: | Used For Transport Coils, Paper Rolls, Etc. |
| Highlight: | coil transfer cart,motorized rail cart |
||
Steel Coil Transporter Car with Upender Device for Transferring
Introduction of Coil Transfer Trolley
The Coil rail transfer trolley can be powered by battery. There are mounted V-shape and roller on Coil rail transfer trolley to protect the coil from falling down from the Coil rail transfer trolley.The V-shape supporting can be designed according to coil diameter, and roller distance can be adjusted as per coil die.V-shape supporting and roller can be removable from the Coil rail transfer trolley.We can design coil Coil rail transfer trolley according to the workshop application, material dimension.It can be applied in all kinds of occasion even severe working environment.
NOTES:
| Model | 2t | 20t | 50t | 100t | 150t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| Table Size(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
| Heigth(H) | 500 | 600 | 700 | 1000 | 1200 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 0.8 | 2.5 | 5.5 | 11 | 15 | |
| Running Distance(m) | 25 | 30 | 50 | 50 | 50 | |
| Max Wheel Load(KN) | 14.4 | 77.7 | 174 | 343.8 | 265.2 | |
| Reference Weight(t) | 2.5 | 5.6 | 7.8 | 14.1 | 26.2 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
